adjustable aLLEYWAYS

LAG Industries manufactures adjustable alleyways from all new #1 steel. These alleyways will adjust from 30” to 18” and have a ratcheting lock so you do not have to mess with the rod and pin latches that most other adjustable alleyways come with. Click on any of the pictures below to make them larger. Check out the videos below to see the products in action and how they operate.
16' LAG Adjustable Alleyway
16' LAG Adjustable Alleyway

Working side view of the Hot Dipped Galvanized 16' Adjustable Alleyway from LAG Industries

press to zoom
16' Adjustable Alleyway
16' Adjustable Alleyway

Rear view of the Hot Dipped Galvanized 16' Adjustable Alleyway from LAG Industries with the side fully open to 30" and no backs engaged

press to zoom
LAG 16' Adjustable Alleyway
LAG 16' Adjustable Alleyway

Rear view of the Hot Dipped Galvanized 16' Adjustable Alleyway from LAG Industries with the side fully open to 30" and no backs locked back out of the way

press to zoom
LAG 16' Adjustable Alleyway
LAG 16' Adjustable Alleyway

Rear view of the Hot Dipped Galvanized 16' Adjustable Alleyway from LAG Industries with the side fully closed to 17 1/2" no backs engaged

press to zoom
LAG 16' Adjustable Alleyay
LAG 16' Adjustable Alleyay

Rear view of the Hot Dipped Galvanized 16' Adjustable Alleyway from LAG Industries with the side fully open and no backs engaged Also Shows the Optional Exit gate on the non adjustable side.

press to zoom
LAG Adjustable Alleyway and Corral
LAG Adjustable Alleyway and Corral

Adjustable Alleyway and gates from LAG

press to zoom
1/1

LAG Industries manufactures adjustable alleyways from all new #1 steel. These alleyways will adjust from 30” to 18” and have a ratcheting lock so you do not have to mess with the rod and pin latches that most other adjustable alleyways come with. The LAG adjustable alleyways are built in either left hand or right hand and can be narrower or wider upon request but they will adjust 12”. The adjustable alleyways from LAG Industries are 7’ tall and can come in any length, the standard sizes are 10’, 12', 16’, 20’ and 24' along with an 8’ scale alleyway which includes dual sliding gates. The framework of the Alleyway is all 2” square tubing and the hinge posts are 1 1/2” P.S. Schedule 40 Pipe. The rails of the alleyways are 1 1/2” x 14ga High Tensile round tubing which is the same materials we use to make our heavy duty 20’ continuous fence panels

The LAG adjustable alleyways are sheeted with 14ga metal up to 57 1/2” allowing easy access to calves and for worming. The alleyways are sold with a horizontal sliding gate or pivot gate that will attach to the front or the rear. They also come with spring loaded no backs built into the working side. Some options available on the alleyways are exit gates, drop gates, palpation cage and additional sliding gates and wheel kits.

LAG Industries highly recommends that you buy all of your equipment in hot dipped galvanized. The reason behind this is every piece of equipment will be built with raw materials and then will be taken to Monnig Industries in Glasgow Missouri to be hot dipped. The reason why hot dipping is far and above better than any kind of paint is because all of the steel is coated inside and out which will not allow the materials to rust out from the inside like the products that are painted will. The other side to the hot dipping that is great is the products are fully submersed in the tank of galvanizing so there are no voids or thin paint areas that will rust and it is the most durable coating that you can get. LAG also offers the products bare or we can get a price on having them powder coated.

Rear Gate Options

LAG Pivot Gate
LAG Pivot Gate

This is the LAG Pivot Gate in the closed position this style of gate takes up the least amount of space and also eliminates overhead bars for knocking your head on

press to zoom
LAG Pivot Gate
LAG Pivot Gate

This is the LAG Pivot Gate in the open position this style of gate takes up the least amount of space and also eliminates overhead bars for knocking your head on

press to zoom
LAG Slide Gate
LAG Slide Gate

This is a traditional sliding gate from LAG in the closed position. This type of sliding gate opens to the side you are standing on

press to zoom
LAG Sliding Gate
LAG Sliding Gate

This is a traditional sliding gate from LAG in the open position. This type of sliding gate opens to the side you are standing on

press to zoom
LAG Opposite Opening Sliding Gate
LAG Opposite Opening Sliding Gate

This is an opposite side opening sliding gate from LAG in the closed position. This type of sliding gate opens to the opposite side of the alleyway with a pass through handle

press to zoom
LAG Opposite Opening Sliding Gate
LAG Opposite Opening Sliding Gate

This is an opposite side opening sliding gate from LAG in the open position. This type of sliding gate opens to the opposite side of the alleyway with a pass through handle

press to zoom
